Excess Supersaturation

Iterations

  • How many periods of excess supersaturation?: this integer value is the number of different periods for supersaturation. After entering value click "generate fields" to generate subsequent question.
  • Iterations at end of period of excess supersaturation n: this question will appear for 2 or more periods of supersaturation.  The first period will start at the first iteration and the final period will end at the final iteration. If you ask for r periods of excess supersaturation you will need to enter r-1 of these questions.


Period n

  • Excess supersaturation in period n for (tile t_xxx/molecule x/group molecule): for every molecule, group of molecules or tile enter the desired excess supersaturation in kcal/mol. This number MUST be positive – unless you are working with a structural solvent such as in a MOF where returning a value of -1 will keep the solvent at an activity of about 1.  Repeat for all growth units for all periods.

Video Tutorials

To help you get started growing crystals with CrystalGrower, we have recorded a series of video guides on our YouTube channel.
